Bowswap ILF Build-along - All Done!

All build alongs are archived here for quick and easy reference.

Re: Bowswap ILF Buildalong - 4 4Nolz

Postby Longbow » Thu Aug 05, 2010 8:44 pm

Bobby, your doing a great build along. Can't wait to see that riser finished
Longbow

Posts: 289
Joined: Sat Apr 26, 2008 9:08 pm
Location: Blackcreek, Wisconsin


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby JGray » Fri Aug 06, 2010 8:12 am

Damn, this is killing me - wish I could see the pictures! Company computers block anything Photobucket or Youtube :(
JGray

Posts: 473
Joined: Mon Apr 27, 2009 7:33 pm
Location: Montana


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby BK in TEXAS » Sun Aug 08, 2010 5:17 am

Out of the oven

Damn...not the greatest glue line. Oh well, should still be fine.

Mike....my taper jig does open to 15˚ :) Worked like a charm cutting the pads.

Both risers. Notice I wrote flat on one side of each riser.

I still want to make sure the pads are flat and square.
I grind them to the line on the disc sander keeping the same side (the flat side) of the riser on the table.
Hooked on Phonics......Helping kids read gooder since 1970.


http://www.NorthlandGameCalls.com
User avatar
BK in TEXAS

Posts: 4930
Joined: Tue Apr 01, 2008 6:43 am
Location: Northwestern Wisconsin


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby BK in TEXAS » Sun Aug 08, 2010 5:22 am

Close enough.....I only need the first 4" to be flat. Everything else gets blended into the backing anyway.

Double checking pad angles....looks good. :)
Hooked on Phonics......Helping kids read gooder since 1970.


http://www.NorthlandGameCalls.com
User avatar
BK in TEXAS

Posts: 4930
Joined: Tue Apr 01, 2008 6:43 am
Location: Northwestern Wisconsin


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby BK in TEXAS » Sun Aug 08, 2010 5:31 am

Now I need to line each pad with some phenolic so I'm gonna rip off a 1 5/8" strip.
1 5/8" because even after cleaning up and squaring the risers, they are still 1 5/8" thick. At some point I'm going to have to take off another 1/8" or so. Cross that bridge when we get there I suppose.

Grind off the glossy release agent.......and walla! One for each pad.

If you're not too anal retentive you can have smooth-on for overlays mixed in about 2 minutes......
A spoonful of each, just eyeball it.
Scrape off spoons (looks like an egg :? )
Drill mix for 45 seconds.....done!
This is about twice as much as needed for the 4 pads by the way. I had a couple other "things" that needed gluing as well.
Hooked on Phonics......Helping kids read gooder since 1970.


http://www.NorthlandGameCalls.com
User avatar
BK in TEXAS

Posts: 4930
Joined: Tue Apr 01, 2008 6:43 am
Location: Northwestern Wisconsin


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby Crooked Stic » Sun Aug 08, 2010 6:18 am

Bobby where did you get that protractor thingy? This riser stuff is what I want to see. Eyeballing glue------do it to ond overlays etc.
Prez of the Crooked Stic Gang
User avatar
Crooked Stic

Posts: 4140
Joined: Thu Jan 17, 2008 9:02 pm
Location: Princeton IN.


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby wantoknow » Sun Aug 08, 2010 6:29 am

I learn more on this site on bow building than any other place online, thanks for sharing and great work.
Want To Know
wantoknow

Posts: 312
Joined: Sun Mar 16, 2008 1:47 pm


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby BK in TEXAS » Sun Aug 08, 2010 6:40 am

Hooked on Phonics......Helping kids read gooder since 1970.


http://www.NorthlandGameCalls.com
User avatar
BK in TEXAS

Posts: 4930
Joined: Tue Apr 01, 2008 6:43 am
Location: Northwestern Wisconsin


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby Crooked Stic » Sun Aug 08, 2010 4:24 pm

Dont we all know anything that has to do with medical is way to pricey.
Prez of the Crooked Stic Gang
User avatar
Crooked Stic

Posts: 4140
Joined: Thu Jan 17, 2008 9:02 pm
Location: Princeton IN.


Re: Bowswap ILF Buildalong - 4 4Nolz

Postby BK in TEXAS » Sun Aug 08, 2010 7:47 pm

Phenolic pads glued on and squared up on the disc sander same as when I cut the pads.

Square. This is pretty important as you'll see in the next step.
Hooked on Phonics......Helping kids read gooder since 1970.


http://www.NorthlandGameCalls.com
User avatar
BK in TEXAS

Posts: 4930
Joined: Tue Apr 01, 2008 6:43 am
Location: Northwestern Wisconsin
